Post Press and Converting Machines for sale
1997 Arpeco Tracker 13" Slitter Rewinder
Shear Slitting, 1" & 3" Core Shafts, Counter,
Ref # 861847091
Click to see video of the machine
Pacific Machinery Development PMD Slitter Rewinder
83" Wide max roll width
64" diameter Unwind w/ 3”, 4”, 5”, 6”, 8”, 12” cores
Slitting width 2” - 82” (up to 13 cuts total)
Minimum size by flipping units: 1-1/8”
58” Rewind w/ 3”, 4”, 5”, 6” cores
Paper caliper: 2# bond to .018 chipboard
J table
Ref #1099648919
Mercury Zerand 45" Web-fed Platen Die Cutter
44" Maximum Width X 36" Long
Zerand 60” Turret Unwind, Decurling Roll Stand Backstand, GWD Web Guide, Intermediate Roll Clamp, Takeaway Conveyor, Stacking Table, 27" x 17" Trim Removal Belt Conveyor
include die making machinery
Ref 3604901651
Saint Regis Tuber
for 6-ply multiwall bags
(6) Unwind up to 72” Wide 50” Diameter
Pinch Bottom w/ Glue
Conveyer Delivery
Ref # 1380718616A
1991 HG Weber Bag machine
For Gussetted bags
Mod#5TBN-1239
Ref # 1380718616B
CMD 3113 Folder - Never Used!
4" - 13" Wide web
Rated to 700 FPM
Designed to separate bags from a perforated web, then fold the bag longitudinally 1-3 times.
Perf length: 16" - 60"
ref # 1691331488
RFID manufacturing line - Mühlbauer TAL 15000 - RFID Bonder, Flip Chip, Tester, w/ Glop Top Module
For HF & UHF inlays
Rated to 13k UPH
Antenna web handling, glue jetting, flip chip attachment, final curing, testing, slitting. All antenna formats (350 mm web width (~ 13 3⁄4 in))
Chip sizes to (0.3 mm x 0.3 mm to 1.5 mm x 1.5 mm)
Glue jetting technology
Quality: typical yield: 99.5% +
100% process control with vision systems at epoxy and chip placement
Plus:
100% inspection rewinds
Carousel conveyors w/ 6 applicators and 3 robots.
FANUK Scara SR-3iA robots
Nautilus Systems PL-165 Label Applicators
5 Color Flexographic Stack Press
Epson Surepress L-4033AW 13 inch 7-Color digital Press
Ref # 2893874588
1994 SHM 1400 DK CTR 55" Wide Sheeter
Single shaft unwind
Max web width: 55"
Cut off range: 16" - 55"
Max knife load multiple webs: 500 gm/m2
Max knife load single web: 400 gm/m2
Pile height max: 47"
Pile weight max with pallet: 3300lbs
Ref # 3967906334
1985 SHM 1400 55" Wide Fixed Bed Sheeter
Single Shaft Unwind
Upgraded gear box
48-inch (1200 mm) Pile height
Sheet Width 55-inch (1400mm) inch maximum
Sheet Length 60-inch (1575mm) maximum
(3) Tidland Slitters
Rated to 1000 FPM (335m/min) maximum mechanical speed
Ref # 3967906683
SHM 1400DK 55" Wide Twin Knife Digital Sheeter
- Totally Upgraded 2018
Rated to 1,000 FPM
(2) SHM Shaftless Backstands w/Montalvo Web Tension Controllers
Overhead Web T1 with Dancer and Idler Rollers
AccuWeb Web Guide System
Cutting Stand with Top and Bottom Slitting Heads
(5) Tidland Class 2 slitter knives
105 HP Motor
Split Belt Takeaway Conveyor; Cut Sheet Pile Stacker
Allen-Bradley Model Panel View Plus PLC
Trim Removal System and Horizontal baler included
Ref # 15769715092
